FQ Easy™ H07Z1-R 450/750 V

Products

H07Z1-R 450/750 V 1,5

Nexans ref. 11485340-207-02 - Country ref. 0437642

  • Packaging: Coil (100m)
  • Colour: Grey
  • Conductor cross-section: 1.5 mm²
  • Nominal outer diameter: 3.0 mm
  • Approximate weight: 2.1 kg/100m



H07Z1-R 450/750 V 1,5

Nexans ref. 11485340-410-02 - Country ref. 0437602

  • Packaging: Coil (100m)
  • Colour: Orange
  • Conductor cross-section: 1.5 mm²
  • Nominal outer diameter: 3.0 mm
  • Approximate weight: 2.1 kg/100m



H07Z1-R 450/750 V 1,5

Nexans ref. 11485340-232-02 - Country ref. 0437672

  • Packaging: Coil (100m)
  • Colour: Yellow / green
  • Conductor cross-section: 1.5 mm²
  • Nominal outer diameter: 3.0 mm
  • Approximate weight: 2.1 kg/100m



H07Z1-R 450/750 V 1,5

Nexans ref. 11485340-411-02 - Country ref. 0437622

  • Packaging: Coil (100m)
  • Colour: Black
  • Conductor cross-section: 1.5 mm²
  • Nominal outer diameter: 3.0 mm
  • Approximate weight: 2.1 kg/100m



H07Z1-R 450/750 V 1,5

Nexans ref. 11485340-412-02 - Country ref. 0437612

  • Packaging: Coil (100m)
  • Colour: White
  • Conductor cross-section: 1.5 mm²
  • Nominal outer diameter: 3.0 mm
  • Approximate weight: 2.1 kg/100m



H07Z1-R 450/750 V 1,5

Nexans ref. 11485340-208-02 - Country ref. 0437662

  • Packaging: Coil (100m)
  • Colour: Brown
  • Conductor cross-section: 1.5 mm²
  • Nominal outer diameter: 3.0 mm
  • Approximate weight: 2.1 kg/100m



H07Z1-R 450/750 V 1,5

Nexans ref. 11485340-204-02 - Country ref. 0437652

  • Packaging: Coil (100m)
  • Colour: Blue
  • Conductor cross-section: 1.5 mm²
  • Nominal outer diameter: 3.0 mm
  • Approximate weight: 2.1 kg/100m



H07Z1-R 450/750 V 1,5

Nexans ref. 11485340-203-02 - Country ref. 0437632

  • Packaging: Coil (100m)
  • Colour: Red
  • Conductor cross-section: 1.5 mm²
  • Nominal outer diameter: 3.0 mm
  • Approximate weight: 2.1 kg/100m



FQ Easy™ 1,5 mm² 450/750 V Violett

Nexans ref. 11485340-211-02 - Country ref. 0437682

  • Packaging: Coil (100m)
  • Colour: Violet
  • Conductor cross-section: 1.5 mm²
  • Nominal outer diameter: 3.0 mm
  • Approximate weight: 2.1 kg/100m



H07Z1-R 450/750 V 2,5

Nexans ref. 11485440-208-02 - Country ref. 0437742

  • Packaging: Coil (100m)
  • Colour: Brown
  • Conductor cross-section: 2.5 mm²
  • Nominal outer diameter: 3.6 mm
  • Approximate weight: 3.3 kg/100m



H07Z1-R 450/750 V 2,5

Nexans ref. 11485440-412-02 - Country ref. 0437702

  • Packaging: Coil (100m)
  • Colour: White
  • Conductor cross-section: 2.5 mm²
  • Nominal outer diameter: 3.6 mm
  • Approximate weight: 3.3 kg/100m



H07Z1-R 450/750 V 2,5

Nexans ref. 11485440-411-02 - Country ref. 0437712

  • Packaging: Coil (100m)
  • Colour: Black
  • Conductor cross-section: 2.5 mm²
  • Nominal outer diameter: 3.6 mm
  • Approximate weight: 3.3 kg/100m



H07Z1-R 450/750 V 2,5

Nexans ref. 11485440-204-02 - Country ref. 0437732

  • Packaging: Coil (100m)
  • Colour: Blue
  • Conductor cross-section: 2.5 mm²
  • Nominal outer diameter: 3.6 mm
  • Approximate weight: 3.3 kg/100m



H07Z1-R 450/750 V 2,5

Nexans ref. 11485440-232-02 - Country ref. 0437752

  • Packaging: Coil (100m)
  • Colour: Yellow / green
  • Conductor cross-section: 2.5 mm²
  • Nominal outer diameter: 3.6 mm
  • Approximate weight: 3.3 kg/100m



H07Z1-R 450/750 V 2,5

Nexans ref. 11485440-207-02 - Country ref. 0437722

  • Packaging: Coil (100m)
  • Colour: Grey
  • Conductor cross-section: 2.5 mm²
  • Nominal outer diameter: 3.6 mm
  • Approximate weight: 3.3 kg/100m



H07Z1-R 450/750 V 2,5

Nexans ref. 11485440-410-02 - Country ref. 0437692

  • Packaging: Coil (100m)
  • Colour: Orange
  • Conductor cross-section: 2.5 mm²
  • Nominal outer diameter: 3.6 mm
  • Approximate weight: 3.3 kg/100m



Description

Description

Standards

  • International
    EN 50525-3-31

H07Z1-R (FQ Easy™) is a halogen free, HFFR-insulated house wiring cable with one circular, stranded copper conductor. The cable is designed according to HD 21.3 in applicable parts. The conductor has resistance and number of wires according to IEC 60228 class 2. The insulation is marked "NEXANS GS SEMKO Ds2d2a2". H07Z1-R (FQ Easy™) meets the requirements for fire classification Dcas2d2a2 according to CPR. The conductor insulation shall be protected against UV light that can occur for example in light fixtures and light signs. The cable is certified by Intertek SEMKO.





Certification

Certified by Intertek SEMKO


Quality and environmental management system

Certified according to ISO 9001, IRIS, ISO/TS 16949 and ISO 14001.

Characteristics

Characteristics

Construction characteristics

Construction characteristics

Conductor material
Copper
Conductor shape
Circular
Conductor flexibility
Stranded class 2
Insulation
Halogen free compound
Halogen free
Yes

Dimensional characteristics

Dimensional characteristics

Number of cores
1

Electrical characteristics

Electrical characteristics

Rated Voltage Uo/U (Um)
450/750 V

Usage characteristics

Usage characteristics

Minimum installation temperature
0 °C
Maximum operating temperature
70 °C
Bending factor when laying
8 (xD)
Smoke density
IEC 61034
Gases corrosivity
IEC 60754-2

Resources

Resources

Selling & delivery Information

FQ Easy™ H07Z1-R is delivered in lengths of 100 m. The drum is marked with manufacturer, type of cable and length.
